Section 2 – Maintenance Tables and Diagrams Maximum Platform Capacities (Evenly Distributed)
Model
Wind
Rating
Total Platform Capacity Extension Platform Capacity
Manual
Force
Tilt Cutout
Setting
3215
ANSI/CSA
0 m/s
[0 mph]
272 kg
[600 lb]
2 Persons
113 kg
[250 lb]
1 Person
400 N
90 lbf
1.5˚ × 3.5˚
12.5 m/s
[28 mph]
1 Person
200 N
45 lbf
3219
ANSI/CSA
0 m/s
[0 mph]
227 kg
[500 lb]
2 Persons
113 kg
[250 lb]
1 Person
400 N
90 lbf
1.5˚ × 3.5˚
12.5 m/s
[28 mph]
1 Person
200 N
45 lbf
3215
CE
0 m/s
272 kg
2 Persons
113 kg 1 Person
400 N
1.5˚ × 3.5˚
12.5 m/s 1 Person 200 N
3219
CE
0 m/s
227 kg
2 Persons
113 kg 1 Person
400 N
1.5˚ × 3.5˚
12.5 m/s 1 Person 200 N
3215
AS
0 m/s
272 kg
2 Persons
113 kg 1 Person
400 N
1.5˚ × 3.5˚
12.5 m/s 1 Person 200 N
3219
AS
0 m/s
227 kg
2 Persons
113 kg 1 Person
400 N
1.5˚ × 3.5˚
12.5 m/s 1 Person 200 N
3215
KC
0 m/s
272 kg
2 Persons
113 kg 1 Person
400 N
1.5˚ × 3.5˚
12.5 m/s 1 Person 200 N
3219
KC
0 m/s
227 kg
2 Persons
113 kg 1 Person
400 N
1.5˚ × 3.5˚
12.5 m/s 1 Person 200 N
2006AA
2.9 Maximum Platform Capacities (Evenly Distributed)Table

Skyjack SJ3219 Specifications

General

Gradeability	25%
Power Source	Electric
Drive Motor	24V DC
Tire Type	Solid, non-marking
Lift Capacity	550 lbs
Machine Width	32 in
Machine Length	70 in
Drive Speed (Stowed)	2 mph
Drive Speed (Raised)	0.8 km/h
Turning Radius (Inside)	0 in (0 m)
Battery	4 x 6V
Working Height	25 ft
