Skyjack SJ3219 Service Manual

36
SJ3215, SJ3219
212508ADA
Section 2 – Maintenance Tables and Diagrams Specifications & Features - AS
* Weight with standard 0.9 m extension platform. Refer to serial nameplate for specific applications.
Models 3215 3219
Weight* 1148 kg 1476 kg
Overall Width 0.82 m
Overall Length
(Platform Retracted)
1.80 m
Overall Length
(Platform Extended)
2.64 m
Platform Size, Inside
(Platform Retracted)
1.54 m
Platform Size Inside
(Platform Extended)
2.39 m
Height
Working Height 6.44 m 7.65 m
Platform Elevated Height 4.44 m 5.65 m
Stowed Height (Railings Down) N/A N/A
Stowed Height (Railings Up) 1.88 m 1.99 m
Drive Height FULL
Standard Operating Times
Lift Time (No Load) 15 s 15 s
Lower Time (No Load) 22 s 32 s
Lift Time (Rated Load) 17 s 17 s
Lower Time (Rated Load) 16 s 24 s
Chassis
Normal Drive Speed 3.38 km/h 3.03 km/h
Elevated Drive Speed 1.13 km/h
Gradeability (Ramp Angle) 25%
Tires (Solid Rubber)
12 x 4 x 8
Hydraulic Oil
Type
ATF DEXRON III
SHELL NATURELLE HF-E 32
Tank Capacity (Liters) 11.3 L
Sound Pressure Level at Platform Level
Does not exceed: 70 db(A)
2004AA
2.7 Specifications & Features - ASTable

Skyjack SJ3219 Specifications

General

Gradeability	25%
Power Source	Electric
Drive Motor	24V DC
Tire Type	Solid, non-marking
Lift Capacity	550 lbs
Machine Width	32 in
Machine Length	70 in
Drive Speed (Stowed)	2 mph
Drive Speed (Raised)	0.8 km/h
Turning Radius (Inside)	0 in (0 m)
Battery	4 x 6V
Working Height	25 ft
