Skyjack SJ3219 Service Manual

A B C D E F G H
V
Z
Y
X
W
68
SJ3215, SJ3219
212508ADA
3.26 Elevate Telematics Harness
M235048AB
3
2 4
1 6
7
8
9 10
11
12
5
IEC 9.1
J1
TO TRACKUNIT
TO BATTERY TO BMS
TO CHARGER
CANH-YL-20-STP
CANL-GN-20-STP
08C-PU/WH-18
19D-WH/RD-18
CANL-GN-20-STP
CANH-YL-20-STP
CANL-GN-20-STP
CANH-YL-20-STP
00-WH-18
05B-PU/BK-18 05B-PU/BK-18
00-WH-18
CANL-GN-20-STP
CANH-YL-20-STP
00-WH-18
05B-PU/BK-18
08D-PU/WH-18
19D-WH/RD-18
SCANH
SCANL
S00
S05B
1A FUSE
S08C S08D
PIN 1 - PLUGGED
PIN 2 - 08D PURPLE/WHITE
PIN 3 - 05B PURPLE/BLACK
PIN 4 - 00 WHITE
PIN 5 - PLUGGED
PIN 6 - PLUGGED
PIN 7 - CANH YELLOW
PIN 8 - CANL GREEN
PIN 9 - 19D WHITE/RED
PIN 10 - PLUGGED
PIN 11 - PLUGGED
PIN 12 - PLUGGED
SCANL
TO BATTERY NEGATIVE
00 - WHITE
00
TO FUSE SUPPLIED WITH TRACKUNIT
05B - PURPLE/BLACK
TO CONTROLLER
CANL - GREEN (P1-6)
CANH - YELLOW (P1-5)
19D - WHITE/RED (P1-4)
CANL
CANH
19D
08C
CANH CANL
TO CHARGER
CANL - GREEN
CANH - YELLOW
J1
S00
1
2
3
4
5
6
7
8
9
10
11
12
05B
08C 08D
S08C
S08D
SCANH
CANL CANH
05B
00
TO BMS HARNESS
00 - WHITE
05B - PURPLE/BLACK
CANL - GREEN
CANH - YELLOW
S05B

Skyjack SJ3219 Specifications

General

Gradeability	25%
Power Source	Electric
Drive Motor	24V DC
Tire Type	Solid, non-marking
Lift Capacity	550 lbs
Machine Width	32 in
Machine Length	70 in
Drive Speed (Stowed)	2 mph
Drive Speed (Raised)	0.8 km/h
Turning Radius (Inside)	0 in (0 m)
Battery	4 x 6V
Working Height	25 ft
