Skyjack SJ3219 Service Manual

34
SJ3215, SJ3219
212508ADA
Section 2 – Maintenance Tables and Diagrams Specifications & Features - ANSI/CSA
2.5 Specifications & Features - ANSI/CSATable
* Weight with standard 0.9 m extension platform. Refer to serial nameplate for specific applications.
Models 3215 3219
Weight*
1148 kg
2531 lb
1476 kg
3255 lb
Overall width
0.82 m
32.28 in
Overall length
(Platform Retracted)
1.80 m
70.87 in
Overall length - RapidFold™
(Platform Retracted)
N/A
1.81 m
71.26 in
Platform Size Inside
(Platform Extended)
0.65 m x 1.54 m
25.59 in x 60.63 in
Height
Working Height
6.27 m
21 ft 2 in
7.48 m
24 ft 6 in
Platform Elevated
Height
4.44 m
14 ft 7 in
5.65 m
18 ft 6 in
Stowed Height
(Railings Down)
1.67 m
65.75 in
1.79 m
70.47 in
Stowed Height - RapidFold™
(Railings Down)
N/A
2.02 m
79.70 in
Stowed Height
(Railings Up)
2.03 m
79.92 in
2.14 m
84.25 in
Drive Height
FULL
Standard Operating Times
Lift Time (No Load)
15 s 15 s
Lower Time (No Load)
22 s 32 s
Lift Time (Rated Load)
17 s 17 s
Lower Time (Rated Load)
16 s 24 s
Chassis
Normal Drive Speed
3.38 km/h
2.1 mph
Elevated Drive Speed
1.13 km/h
0.7 mph
Gradeability (Ramp Angle)
25%
Tires (Solid Rubber)
12 x 4 x 8
Hydraulic Oil
Type
ATF Dexron III
SHELL NATURELLE HF-E 32
Tank Capacity (Liters)
11.3 L (3 gal)
Sound Pressure Level at Platform Level
Does not exceed: 70 db(A)
2002AB

Skyjack SJ3219 Specifications

General

Gradeability	25%
Power Source	Electric
Drive Motor	24V DC
Tire Type	Solid, non-marking
Lift Capacity	550 lbs
Machine Width	32 in
Machine Length	70 in
Drive Speed (Stowed)	2 mph
Drive Speed (Raised)	0.8 km/h
Turning Radius (Inside)	0 in (0 m)
Battery	4 x 6V
Working Height	25 ft
