Section 2 – Maintenance Tables and Diagrams Torque Specifications for Fasteners (Metric)
2.3 Torque Specifications for Fasteners (Metric)Table
Size
Torque
Type
8.8 10.9
Dry Lubed Dry Lubed
M5 x 0.80
(in-lb) (54) (41) (78) (59)
Nm 6.1 4.6 8.8 6.7
M6 x 1.00
(in-lb) (92) (69) (133) (99)
Nm 10.4 7.8 15 11.2
M7 x 1.00
(in-lb) (156) (116) (222) (167)
Nm 17.6 13.1 25.1 18.9
M8 x 1.25
(in-lb) (225) (169) (333) (242)
Nm 25.4 19.1 37.6 27.3
M10 x 1.50
ft-lb 37 28 53 40
Nm 50 38 72 54
M12 x 1.75
ft-lb 65 49 93 69
Nm 88 66 126 94
M14 x 2.00
ft-lb 104 78 148 111
Nm 141 106 201 150
M16 x 2.00
ft-lb 161 121 230 172
Nm 218 164 312 233
M18 x 2.50
ft-lb 222 167 318 238
Nm 301 226 431 323
M20 x 2.50
ft-lb 314 235 449 337
Nm 426 319 609 457
M22 x 2.50
ft-lb 428 321 613 460
Nm 580 435 831 624
M24 x 3.00
ft-lb 543 407 776 582
Nm 736 552 1052 789
M27 x 3.00
ft-lb 796 597 1139 854
Nm 1079 809 1544 1158
M30 x 3.50
ft-lb 1079 809 1543 1158
Nm 1463 1097 2092 1570
M33 x 3.50
ft-lb 1468 1101 2101 1576
Nm 1990 1493 2849 2137
M36 x 4.00
ft-lb 1886 1415 2699 2024
Nm 2557 1918 3659 2744
NOTE: Lubed includes lubricants such as lubrizing, oil, grease,
or uncured Loctite.
1375AB

Skyjack SJ3219 Specifications

General

Gradeability	25%
Power Source	Electric
Drive Motor	24V DC
Tire Type	Solid, non-marking
Lift Capacity	550 lbs
Machine Width	32 in
Machine Length	70 in
Drive Speed (Stowed)	2 mph
Drive Speed (Raised)	0.8 km/h
Turning Radius (Inside)	0 in (0 m)
Battery	4 x 6V
Working Height	25 ft
