Skyjack SJ3219 Service Manual

45
SJ3215, SJ3219
212508ADA
Hydraulic Parts List Section 3 – System Component Identification and Schematics
3.4 Hydraulic Parts List
Index
No.
Skyjack
Part No.
Description
2H-13 103655 VALVE, Lower (SJ3219)
2H-13C 207870 VALVE, Lower (SJ3215)
3H-14 106273 VALVE, Lift
3H-17 103623 VALVE, Brake
4H-15 153334 VALVE, Reverse
4H-16 153334 VALVE, Forward
4H-23A 153334 VALVE, Steer Right
4H-24A 153334 VALVE, Steer Left
BR1 217960 BRAKE, Hydraulic (CE, AS & KC)
BR2 217960 BRAKE, Hydraulic (CE, AS & KC)
C1 226482 CYLINDER, Lift
C2 151733 CYLINDER, Steering
C3 204005 CYLINDER, Brake (ANSI/CSA)
CB1 147888 COUNTERBALANCE, Motors
F1 109568 FILTER, Return
M1 161094 MOTOR, Left (ANSI/CSA, CE & KC)
194615 MOTOR, Left (AS)
M2 161094 MOTOR, Right (ANSI/CSA, CE & KC)
194615 MOTOR, Right (AS)
MB1 226496 MANIFOLD, Main (SJ3215 ANSI/CSA)
226497 MANIFOLD, Main (SJ3215 CE, AS & KC)
226479 MANIFOLD, Main (SJ3219 ANSI/CSA)
226481 MANIFOLD, Main (SJ3219 CE, AS & KC)
MB2 138021 MANIFOLD, Free-Wheel
MB3 212912 MANIFOLD, Holding
MB4 209218 MANIFOLD, Brake Release (CE, AS & KC)
01 310056 ORIFICE, Steer - 0.040" (SJ3215)
02 310056 ORIFICE, Steer - 0.040" (SJ3215)
03 226498 ORIFICE, 0.094" (SJ3215)
226477 ORIFICE, 0.059" (SJ3219)
04 147656 ORIFICE, 0.024"
05 130407 ORIFICE, 0.051" (ANSI/CSA)
P1 161936 PUMP, DC Motor
165610 PUMP, DC Motor (ANSI/CSA EE-Rated)
P2 146559 PUMP, DC Motor (CE, AS & KC)
QD1 122420 QUICK DISCONNECT
R1 104534 RELIEF, System
R2 104534 RELIEF, Lift
SN1 210292 SNUBBER, 5um
V1 103136 VALVE, Free-Wheel
V2 146561 VALVE, Brake Override (CE, AS & KC)

Skyjack SJ3219 Specifications

General

Gradeability	25%
Power Source	Electric
Drive Motor	24V DC
Tire Type	Solid, non-marking
Lift Capacity	550 lbs
Machine Width	32 in
Machine Length	70 in
Drive Speed (Stowed)	2 mph
Drive Speed (Raised)	0.8 km/h
Turning Radius (Inside)	0 in (0 m)
Battery	4 x 6V
Working Height	25 ft
