Skyjack SJ3219 Service Manual

46
SJ3215, SJ3219
212508ADA
Section 3 – System Component Identification and Schematics Electrical Parts List
Index
No.
Skyjack
Part No.
Description
2H-13 104410 COIL, 12 Volt - Holding Valve
3H-14 105610 COIL, 24 Volt - Lift
4H-15 153334 COIL, 24 Volt - Reverse
4H-16 153334 COIL, 24 Volt - Forward
3H-17 103605 COIL, 24 Volt - Brake
4H-23A 153334 COIL, 24 Volt - Right Steer
4H-24A 153334 COIL, 24 Volt - Left Steer
AT1 220597 TRANSDUCER, Angle
B1-4 103480 BATTERY, 6V - US 2200
106552 BATTERY, 6V - US 250
160933 BATTERY, 6V - AGM
BC1 122093 INDICATOR, Battery Charge
BP29 170620 BEEPER, All Motion, Tilt & Overload
C1 146475 CONTACTOR, Motor
CB1 117325 BREAKER, Circuit - 15A
CB2 408526 BREAKER, Circuit - 10A
CM1 217926 CONTROLLER, Skycoded Module
DCM1 169260 MOTOR
DXX 102921 DIODE
F1 310517 FUSE, 300A
F2 146442 FUSE, 100A - Inverter (ANSI/CSA)
FL-22 235775 LIGHT, Flashing
H1 146649 Horn
LS1 210226 LIMIT SWITCH, Pothole Protection - Hydraulic Tray Side
LS2 210227 LIMIT SWITCH, Pothole Protection - Battery Tray Side
LS7A 208038 LIMIT SWITCH, Anti-Overrising Posts - 64"
LS7B 208039 LIMIT SWITCH, Anti-Overrising Posts - 108"
LS7C 220080 LIMIT SWITCH, Anti-Overrising Posts - Additional Posts
LS7D 220080 LIMIT SWITCH, Anti-Overrising Posts - Additional Posts
PL-1 147061 LIGHT, Platform - Emergency Stop/Overload
PL-2 147061 LIGHT, Base - Emergency Stop/Overload
PT1 217934 TRANSDUCER, Pressure - 3000 PSI (SJ3219)
217933 TRANSDUCER, Pressure - 2000 PSI (SJ3215)
S1 210051 SWITCH, Main Disconnect
S2 147054 SWITCH, Lift/Lower
S3 207741 SWITCH, Lift/Off/Drive
S4 147053 SWITCH, Platform - Emergency Stop
S5 220494 SWITCH, SGLE
3.5 Electrical Parts List

Skyjack SJ3219 Specifications

General

Gradeability	25%
Power Source	Electric
Drive Motor	24V DC
Tire Type	Solid, non-marking
Lift Capacity	550 lbs
Machine Width	32 in
Machine Length	70 in
Drive Speed (Stowed)	2 mph
Drive Speed (Raised)	0.8 km/h
Turning Radius (Inside)	0 in (0 m)
Battery	4 x 6V
Working Height	25 ft
