Page #47 background imageLoading...
Page #47 background image
47
SJ3215, SJ3219
212508ADA
Electrical Parts List Section 3 – System Component Identification and Schematics
Index
No.
Skyjack
Part No.
Description
S7 211751 JOYSTICK
S7-1 119725 SWITCH, Neutral
S7-2 159613 SWITCH, Right
S7-3 159613 SWITCH, Left
S7-6 159067 SWITCH, Enable
S8 147054 SWITCH, Horn
S10 149536 SWITCH, Key - Idle/Platform/Base (ANSI/CSA, AS & KC)
147057 SWITCH, Key - Idle/Platform/Base (CE)
S27 115574 SWITCH, Torque
S28 147053 SWITCH, Base - Emergency Stop
S51 212204 SWITCH, Emergency Lowering

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Skyjack SJ3219 and is the answer not in the manual?

Skyjack SJ3219 Specifications

General IconGeneral
Gradeability25%
Power SourceElectric
Drive Motor24V DC
Tire TypeSolid, non-marking
Lift Capacity550 lbs
Machine Width32 in
Machine Length70 in
Drive Speed (Stowed)2 mph
Drive Speed (Raised)0.8 km/h
Turning Radius (Inside)0 in (0 m)
Battery4 x 6V
Working Height25 ft
