Skyjack SJ3219 Service Manual

57
SJ3215, SJ3219
212508ADA
Anti-Overrising Limit Switch Harness (KC Only) Section 3 – System Component Identification and Schematics
M211893AB_M212438AB
CAVITY COLOUR
LABEL
1
GREEN 08C
2 NOT USED
3
WHITE 51A
4 BLACK
51
Anti-Overrising Posts - Scissor Harness
ID #
COLOUR
LABEL
1
GREEN 08C
2 NOT USED
3
WHITE 51A
4 BLACK
51
ID #
COLOUR
LABEL
1
GREEN 08C
2
RED
52A
3
WHITE 51A
4 BLACK
51
1
2
4
3
ID #
COLOUR
LABEL
1
GREEN 08C
2 BLACK 08C
3
WHITE 51A
4
RED
52A
1
2
4
3
3
4
2
1
3
4
2
1
3
4
2
1
51A - WHITE
51 - BLACK
52A - RED
51A - WHITE
51 - BLACK
08C - GREEN
08C - GREEN
52A - RED
51A - WHITE
08C - BLACK
08C - GREEN
S51A
S08C
SCHEMATIC VIEW
Anti-Overrising Posts - Platform Harness
3.15 Anti-Overrising Limit Switch Harness (KC Only)

Skyjack SJ3219 Specifications

General

Gradeability	25%
Power Source	Electric
Drive Motor	24V DC
Tire Type	Solid, non-marking
Lift Capacity	550 lbs
Machine Width	32 in
Machine Length	70 in
Drive Speed (Stowed)	2 mph
Drive Speed (Raised)	0.8 km/h
Turning Radius (Inside)	0 in (0 m)
Battery	4 x 6V
Working Height	25 ft
