Skyjack SJ3219 Service Manual

146
SJ3215, SJ3219
212508ADA
Skycoded Module Section 5 – Procedures
Help Messages and Fault Codes (Continued)
Code Message Description
Flash
Code
153 LOWERING! N/A
154 NOT CALIBRATED
Height and load based functions are required (for example platform overload is
configured), but height and/or load has not been calibrated.
1/1
155 OVERRIDE MODE
MEWP is in Override mode. Do not operate in this mode, for servicing only.
Cycle power to reset.
N/A
156 OVERRIDE= N/A
157 OVERRISE FAULTY KC only - check anti-overrise limit switches to P3-10 and P3-11. N/A
158
RELEASE GROUND
SWITCHES!
Base function switches were closed at power-on (or a wiring error is causing an
input to be active always).
2/2
159
RELEASE JOYSTICK
SWITCHES!
Platform joystick S7 switches were closed at power-on (or a wiring error is
causing an input to be active always).
Platform joystick switches were closed for too long without trigger switch (see
SETUPS/ INTERLOCKS/TRIGGERwait).
2/2
160 RELEASE TRIGGER!
Trigger switch S7-6 Enable was closed at power-on (or a wiring error is causing
the input to be active always).
Trigger switch was closed for too long with no function selected (see SETUPS/
INTERLOCKS/ TRIGGERonly).
2/2
161 RETRACTING DECK!
All the above HELP messages indicate that a function is active – the machine
should be moving as requested by the operator.
N/A
162 S/N= N/A
163
SELECT DRIVE/LIFT
MODE!
There is a problem with the platform S3 Drive/Lift select switch – neither mode is
selected.
Check wiring from S3 Drive/Lift select switch.
2/2
164
SHUTDOWN -
CHECK EMS
SWITCHES!
The platform and base EMS inputs indicate the mode in which the Control
Module CM1 must operate. If neither input is active, or if both are active together,
the Control Module CM1 does not know how to function.
Check EMS switch wiring to P3-1 and P4-1.
2/1
165 STARTUP!
The Control Module CM1 has just been powered on and is carrying out some
initialization steps prior to being ready to operate. If you select a function during
this time, it may be locked out until you release then re-select it.
N/A
166 STEERING! N/A
167 VEHICLE TILTED
The machine is tilted beyond the limits set by ADJUSTMENTS/TILT/Xtrip and
Ytrip; some functions may be prevented
N/A

Skyjack SJ3219 Specifications

General

Gradeability	25%
Power Source	Electric
Drive Motor	24V DC
Tire Type	Solid, non-marking
Lift Capacity	550 lbs
Machine Width	32 in
Machine Length	70 in
Drive Speed (Stowed)	2 mph
Drive Speed (Raised)	0.8 km/h
Turning Radius (Inside)	0 in (0 m)
Battery	4 x 6V
Working Height	25 ft
