Deutz Diesel Engines Section 5 – Procedures
5.6-6 Deutz TD2.9L Fault Codes
Code SPN FMI Blink Code Error Identification
417 171 3 3-1-2
Sensor error SCR-System environment temperature.
DPF-System air inlet temperature, signal range check high.
418 171 4 3-1-2
Sensor error SCR-System environment temperature.
DPF-System air inlet temperature, signal range check low.
419 190 8 2-1-2 Sensor camshaft speed, disturbed signal.
420 190 12 2-1-2
Sensor camshaft detection.
Out of range, signal disrupted, no signal.
421 190 2 2-1-3 Offset angle between crank- and camshaft-sensor is too large.
422 190 8 2-1-2
Sensor crankshaft detection.
Out of range, signal disrupted or no signal.
423 190 12 2-1-2 Speed detection, out of range, signal disrupted or no signal.
455 975 5 2-3-8 PWM-Signal fan, open load or short-circuit ground.
457 975 3 2-3-8 PWM-Signal fan, short-circuit to battery.
458 975 4 2-3-8 PWM-Signal fan, open load or short circuit to ground
459 1639 12 2-3-8 Fan speed sensor, electrical error, signal disturbed or very low fan speed.
460 1639 0 2-3-8
Sensor error fan speed.
Signal range check high or engine speed resp. Fan speed too big.
461 1639 1 2-3-8 Sensor error fan speed, signal range check low or fan speed too low.
462 523602 0 2-3-8 High fan speed, warning threshold exceeded.
463 523602 0 2-3-8 High fan speed, shut off threshold exceeded.
464 97 3 2-2-8 Sensor error water in fuel, signal range check high.
465 97 4 2-2-8 Sensor error water in fuel, signal range check low.
472 94 3 2-1-6 Sensor error low fuel pressure, signal range check high.
473 94 4 2-1-6 Sensor error low fuel pressure, signal range check low.
474 94 1 2-1-6 Low fuel pressure, warning threshold exceeded.
475 94 1 2-1-6 Low fuel pressure, shut off threshold exceeded.
483 174 11 2-2-7 Fuel temperature not plausible.
486 523618 3 1-3-3 Sensor error gearbox oil temperature, signal range check high.
487 523618 4 1-3-3 Sensor error gearbox oil temperature, signal range check low.
488 523619 2 1-3-3
Physical range check high for exhaust gas temperature upstream (SCR-
CAT).
489 523619 2 1-3-3
Shutoff condition.
No detailed information!
500 523915 0 1-6-5 HCI dosing valve (DV1); overcurrent at the end of the injection phase
501 523915 12 1-6-6 HCI dosing valve (DV1): Powerstage over temperature.
502 523915 3 1-5-9 HCI dosing valve (DV1): Short circuit to battery.
503 523915 3 1-6-4 Short circuit to battery high side, HCI dosing valve (DV1).
504 523915 4 1-5-9 HCI dosing valve (DV1): Short circuit to ground.
505 523915 11 1-6-4 HCI dosing valve (DV1): Short circuit high side powerstage.
