Skyjack SJ82 T Service Manual

226
SJ82 T, SJ86 T
229040ABA
Section 5 – Procedures Deutz Diesel Engines
5.6-6 Deutz TD2.9L Fault Codes
Code SPN FMI Blink Code Error Identification
506 523916 2 7-1-9 Sensor HCI dosing valve (DV1) downstream pressure: Plausibility error.
508 523916 0 7-1-9
HCI dosing valve (DV1) downstream pressure: Physical range check high.
Shut off regeneration.
511 523916 1 7-1-9
HCI dosing valve (DV1) downstream pressure: Physical range check low.
Shut off regeneration.
514 523916 3 7-1-9
Sensor error HCI dosing valve (DV1) downstream pressure: Signal range
check high.
515 523916 4 7-1-9
Sensor error HCI dosing valve (DV1) downstream pressure: Signal range
check low.
525 523917 4 7-1-8 Sensor error DV1 & DV2 upstream pressure: Signal range check low.
534 523918 3 7-1-7 Sensor error DV1 & DV2 upstream temperature: Signal range check high.
535 523918 4 7-1-7 Sensor error DV1 & DV2 upstream temperature: Signal range check low.
542 1638 2 3-1-4 Hydraulic oil temperature check for Shut off condition.
543 676 11 263 Cold start aid relay error.
544 676 11 263 Cold start aid relay: Open load.
545 729 5 263 Cold start aid relay open load.
547 729 12 263 Cold start aid relay: Over temperature error.
549 729 3 263 Intake Air Heater Device: Short circuit to battery.
551 729 4 263
559 523895 13 1-5-8 Check of missing injector adjustment value programming (IMA) injector 1.
560 523896 13 1-5-8 Check of missing injector adjustment value programming (IMA) injector 2.
561 523897 13 1-5-8 Check of missing injector adjustment value programming (IMA) injector 3.
562 523898 13 1-5-8 Check of missing injector adjustment value programming (IMA) injector 4.
563 523899 13 1-5-8 Check of missing injector adjustment value programming (IMA) injector 5.
564 523900 13 1-5-8 Check of missing injector adjustment value programming (IMA) injector 6.
565 523350 4 151 Injector cylinder-bank 1: Short circuit.
566 523352 4 152 Injector cylinder-bank 2: Short circuit.
567 523354 12 153 Injector powerstage output defect.
568 651 5 154 Injector 1 (in firing order): Interruption of electric connection.
569 652 5 155 Injector 2 (in firing order): Interruption of electric connection.
570 653 5 156 Injector 3 (in firing order): Interruption of electric connection.
571 654 5 161 Injector 4 (in firing order): Interruption of electric connection.
572 655 5 162 Injector 5 (in firing order): Interruption of electric connection.
573 656 5 163 Injector 6 (in firing order): Interruption of electric connection.
575 523756 14 1-5-5 Special pattern for special cases. No detailed information!
576 523757 14 1-5-6 Special pattern for special cases. No detailed information!
577 523758 14 1-6-1 Special pattern for special cases. No detailed information!
1513AA-6
