Deutz Diesel Engines Section 5 – Procedures
5.6-6 Deutz TD2.9L Fault Codes
Code SPN FMI Blink Code Error Identification
970 624 12 5-1-3 SVS lamp: powerstage over temperature
971 624 3 5-1-3 SVS lamp; short circuit to battery
972 624 4 5-1-3 SVS lamp; short circuit to ground
973 523612 14 5-5-5 Softwarereset CPU SWReset_0
974 523612 14 5-5-5 Softwarereset CPU SWReset_1
975 523612 14 5-5-5 Softwarereset CPU SWReset_2
976 91 11 2-2-6 Plausibility error between APP1 and APP2 or APP1 and idle switch.
978 29 2 1-2-6
Plausibility error between sensor and idle switch, Acceleratio Pedal
Detection.
In case of Hand Throttle with Low Idle Switch, it is the plausibility check
between hand throttle and idle switch.
980 523550 12 5-1-5 Terminal 50 was operated too long.
981 172 3 2-2-6 Air flow temperature sensor; short circuit to battery or open load.
982 172 4 2-2-6 Air flow temperature sensor; short circuit to ground.
986 523921 0 7-1-4 Burner temperature, temperature above upper shutoff threshold.
989 523921 1 7-1-4 Burner temperature, temperature below lower shutoff threshold.
992 105 1 1-2-8
Charged Air cooler down stream temperature. Temperature below lower
physical threshold.
994 105 3 1-2-8 Electrical error charged air temperature. Signal range check high.(SRC)
995 105 4 1-2-8 Electrical error charged air temperature. Signal range check low.
996 105 0 2-3-3
Charged air cooler temperature. System reaction initiated. High charged air
cooler temperature. Warning threshold exceeded.
997 105 0 2-3-3 High charged air cooler temperature. Shut off threshold exceeded.
998 105 11 1-2-8
Diagnostic fault check for charged air cooler downstream temperature
sensor
No detailed information!
1007 412 3 6-8-2
Electrical error EGR cooler downstream temperature. Signal range check
high.
1008 412 4 6-8-2 electrical error EGR cooler downstream temperature. Signal range check low.
1011 523960 0 7-7-1 Physical range check high for EGR cooler downstream temperature.
1012 523960 1 7-7-1 Physical range check low for EGR cooler downstream temperature.
1014 51 6 5-9-4
Actuator error EGR-Valve (2.9;3.6) or Throttle-Valve (4.1;6.1;7.8).
Signal range check high.
1015 520521 5 5-9-4
Actuator error EGR-Valve (2.9;3.6) or Throttle-Valve (4.1;6.1;7.8); signal range
check low.
1016 51 7 5-9-4
Actuator position for EGR-Valve (2.9;3.6) or Throttle-Valve (4.1;6.1;7.8) not
plausible.
1022 51 6 5-9-4
Actuator error EGR-Valve (2.9;3.6) or Throttle-Valve (4.1;6.1;7.8); signal range
check high
1513AA-13
