Skyjack SJ82 T Service Manual

58
SJ82 T, SJ86 T
229040ABA
Section 3 – System Component Identification and Schematics Electrical Parts List
Index
No.
Skyjack
Part No.
Description
121CR 127131 RELAY, 12 Volt 40 Amp (Boom down enable) - ANSI/CSA
121CR2 127131 RELAY, 12 Volt 40 Amp (Telescope out enable) - ANSI/CSA
121CR3 127131 RELAY, 12 Volt 40 Amp (High capacity light) - ANSI/CSA
121CR4 127131 RELAY, 12 Volt 40 Amp (High capacity light) - ANSI/CSA
123CR 127131 RELAY, 12 Volt 40 Amp (Load capacity enable) - ANSI/CSA
123CR 127131 RELAY, 12 Volt 40 Amp (Load sense fault - boom down) - CE & AS
123CR1 127131 RELAY, 12 Volt 40 Amp (Load sense fault - telescope out) - CE & AS
162BCR 127131 RELAY, 12 Volt 40 Amp (Overload counter)
165CR 127131 RELAY, 12 Volt 40 Amp (Diff lock)
2H-19 159839 COIL, 12 Volt (Lift cushion valve)
2H-21A 159821 COIL, 12 Volt (Dump valve)
2H-42 159819 COIL, 12 Volt (Flow enable valve)
2H-85 168056 COIL, 12 Volt (Optional 3.5 kW generator valve)
3H-26 159827 COIL, 12 Volt (Brake valve)
3H-45A 159827 COIL, 12 Volt (2 speed valve)
3H-65 159827 COIL, 12 Volt (Axle lockout valve)
3H-165 159827 COIL, 12 Volt (Differential lock valve)
3H-V1 N/A COIL, 12 Volt (Pressure compensator)
3H-V2 N/A COIL, 12 Volt (Load sense compensator)
4H-13 159820 COIL, 12 Volt (Boom down valve)
4H-14 159820 COIL, 12 Volt (Boom up valve)
4H-15 N/A COIL, 12 Volt (Reverse drive valve)
4H-16 N/A COIL, 12 Volt (Forward drive valve)
4H-34 159821 COIL, 12 Volt (Jib down valve) - SJ86 T
4H-35 159821 COIL, 12 Volt (Jib up valve) - SJ86 T
4H-36 159819 COIL, 12 Volt (Platform left rotate valve)
4H-37 159819 COIL, 12 Volt (Platform right rotate valve)
4H-38 159820 COIL, 12 Volt (Boom in valve)
4H-39 159820 COIL, 12 Volt (Boom out valve)
4H-40 159821 COIL, 12 Volt (Platform level down valve)
4H-41 159821 COIL, 12 Volt (Platform level up valve)
5H-23A 159821 COIL, 12 Volt (Steer right valve)
5H-24A 159821 COIL, 12 Volt (Steer left valve)
5H-32 159820 COIL, 12 Volt (Turret rotate left valve)
5H-33 159820 COIL, 12 Volt (Turret rotate right valve)
A1 138224 JOYSTICK (Drive/steer)
A2 138225 JOYSTICK (Boom/turret)
A3 138226 CONTROLLER, Speed control selector
AT1 166163 SWITCH, Tilt (analog 28°)
B1 103295 BATTERY, 12V (Wet)
B2 103295 BATTERY, 12V (Wet)
BP1 103057 BEEPER, 4-28 VDC Slow pulsing (Platform control console)
BP2 103056 BEEPER, 7.5-16 VDC (Base control console) - ANSI/CSA
BP3 144387 ALARM, Overload - CE & AS
CB1 117325 CIRCUIT BREAKER (15 Amp)
CB2 117325 CIRCUIT BREAKER (15 Amp)
CB3 117325 CIRCUIT BREAKER (15 Amp)
