Skyjack SJ82 T Service Manual

59
SJ82 T, SJ86 T
229040ABA
Electrical Parts List Section 3 – System Component Identification and Schematics
Index
No.
Skyjack
Part No.
Description
CB4 117326 CIRCUIT BREAKER (20 Amp)
CB5 141631 CIRCUIT BREAKER (50 Amp)
CB6 141630 CIRCUIT BREAKER (15 Amp)
DXX 102921 DIODE
FU1 138848 FUSE, 50 Amp
FS1 138230 SWITCH, Low fuel
H1 146652 HORN, 12 Volt
LB1 169001 LIGHT, Work (optional)
LB2 169001 LIGHT, Work (optional)
LB3 144078 LIGHT, Flashing (optional)
LS1 111356 LIMIT SWITCH, Direction sensing
LS2 165090 LIMIT SWITCH, Boom Angle - Creep
LS3 165429 LIMIT SWITCH, Boom Extend/Retract - Creep
LS4 168762 LIMIT SWITCH, Boom Angle - Dual Load
LS5 165428 LIMIT SWITCH, Boom Extend/Retract - Dual Load
M1 170713 PUMP, Emergency
PL1 147229 LED BLOCK, Red (12 volts) (Base control console)
PL2 138229 MODULE, Upper indicating
PL3 170502 LIGHT, Amber (Engine failure) (Base control console)
PL4 170502 LIGHT, Amber (Low fuel) (Base control console)
PL5 164832 LIGHT, Red (Oil pressure) (Base control console)
PL6 171501 LIGHT, Green (Glow plug) (Base control console)
PL7 164832 LIGHT, Red (Engine temperature) (Base control console)
PL8 170502 LIGHT, Amber (Water in fuel) (Base control console)
PL9 147229 LED BLOCK, Red (12 volts) (Platform control console)
PL10 170501 LIGHT, Green (Low capacity) (Platform control console)
PL11 170501 LIGHT, Green (High capacity) (Platform control console)
PL12 170501 LIGHT, Green (Low capacity) (Base control console)
PL13 170501 LIGHT, Green (High capacity) (Base control console)
PL14 170502 LIGHT, Amber (Load zone border) (Base control console)
PL15 171502 LIGHT, Amber (Load zone border) (Platform control console)
PL16 171502 LIGHT, Amber (Differential lock) (Platform control console)
R1 144714 RESISTOR, 7 ohm 25 W
R2 168783 RESISTOR, 4 ohm 25 W - Deutz D2011
144523 RESISTOR, 7 ohm 25 W - ANSI/CSA Deutz TD2.9L
144714 RESISTOR, 6 ohm 25 W - CE Deutz TD2.9L
R3 144523 RESISTOR, 7 ohm 25 W - Deutz D2011
163021 RESISTOR, 120 ohm 1/2 W - Deutz TD2.9L
R4 172005 RESISTOR, 3 ohm 25 W - ANSI/CSA Deutz D2011
139088 RESISTOR, 6 ohm 25 W - CE & AS D2011
164855 RESISTOR, 1.0k ohm 1/2 W - Deutz TD2.9L
R5 143952 RESISTOR, 51 ohm 2 W - Deutz D2011
164856 RESISTOR, 3.3k ohm 1/22 W - Deutz TD2.9L
R6 172005 RESISTOR, 3 ohm 25 W - ANSI/CSA Deutz D2011
168783 RESISTOR, 4 ohm 25 W - CE & AS Deutz D2011
164857 RESISTOR, 3.9k ohm 1/2 W - Deutz TD2.9L
R7 151643 RESISTOR, 250 ohm 1 W
