Skyjack SJ82 T Service Manual

60
SJ82 T, SJ86 T
229040ABA
Section 3 – System Component Identification and Schematics Electrical Parts List
Index
No.
Skyjack
Part No.
Description
R8 151643 RESISTOR, 250 ohm 1 W
R9 151643 RESISTOR, 250 ohm 1 W
R10 151643 RESISTOR, 250 ohm 1 W
R11 151643 RESISTOR, 250 ohm 1 W
R12 171987 RESISTOR, 1 ohm 1/4 W - Deutz D2011
168783 RESISTOR, 4 ohm 25 W - Deutz TD2.9L
R13 139088 RESISTOR, 6 ohm 25 W - ANSI/CSA Deutz TD2.9L & D2011
171987 RESISTOR, 1 ohm 1/4 W - CE & AS Deutz D2011
R14 172005 RESISTOR, 3 ohm 25 W - Deutz D2011 & ANSI/CSA Deutz TD2.9L
168783 RESISTOR, 4 ohm 25 W - CE Deutz TD2.9L
R15 144714 RESISTOR, 11 ohm 25 W - ANS/CSA
171988 RESISTOR, 2 ohm 25 W - CE & AS Deutz D2011
139088 RESISTOR, 6 ohm 25 W - CE Deutz TD2.9L
R16 171988 RESISTOR, 2 ohm 25 W - ANSI/CSA Deutz D2011 & CE TD2.9L
172005 RESISTOR, 1 ohm 1/4 W - ANSI/CSA Deutz TD2.9L
R17 138783 RESISTOR, 4 ohm 25 W - ANSI/CSA Deutz TD2.9L
171987 RESISTOR, 1 ohm 1/4 W - CE Deutz TD2.9L
R18 171988 RESISTOR, 1 ohm 25 W - ANSI/CSA Deutz TD2.9L
171987 RESISTOR, 1 ohm 1/4 W - CE Deutz TD2.9L
S1 119725 SWITCH, Main power disconnect
S2 138277 KEYSWITCH, Base/Off/Platform (Base control console) - ANSI/CSA&AS
144366 KEYSWITCH, Base/Off/Platform (Base control console) - CE
S3 147053 N.C. CONTACT, Emergency stop (Base control console)
S4 147053 N.C. CONTACT, Emergency stop (Platform control console)
S5 138278 SWITCH, Ignition/emergency pump toggle (Base control console)
S6 138278 SWITCH, Ignition/emergency toggle (Platform control console)
S8 102853 SWITCH, Diagnose toggle (Base control console)
S9 124446 SWITCH, Ignition (Platform control console)
S10 115747 SWITCH, Throttle toggle (Platform control console)
S11 154127 FOOTSWITCH
S12 138278 SWITCH, Boom up/down toggle (Base control console)
S13 102853 SWITCH, Turret rotate toggle (Base control console)
S14 102853 SWITCH, Telescope in/out toggle (Base control console)
S15 102853 SWITCH, Platform leveling toggle (Base control console)
S16 102853 SWITCH, Platform rotate toggle (Base control console)
S17 102853 SWITCH, Jib up/down toggle (Base control console) (SJ86 T)
S18 102853 SWITCH, Telescope in/out toggle (Platform control console)
S19 102853 SWITCH, Platform leveling toggle (Platform control console) - ANSI/CSA
S20 102853 SWITCH, Platform rotate toggle (Platform control console)
S21 102853 SWITCH, Jib up/down toggle (Platform control console) - SJ86 T
S22 144266 SWITCH, Electrical generator (Platform control console)
S23 147054 SWITCH, Horn (Platform control console)
S24 168678 SWITCH, Load zone toggle (Platform control console)
S25 148988 SWITCH, Load zone select (Base control console)
S28 148988 SWITCH, Differential lock (Platform control console)
S48 115574 SWITCH, Drive torque toggle (Platform control console)
TT1 103336 HOUR METER - ANSI/CSA
