146
Section 5 – Procedures Platform
P3 (White)
Pin Wire Function Input/Output Type IO Name Label Expected Value
1 42 Jib/Platform Flow Enable DIGITAL OUTPUT P30 DOUT1 0V/12V
2 01 Emergency Pump Relay DIGITAL OUTPUT P37 DOUT8 0V/12V
3 23A Steer Right DIGITAL OUTPUT P36 DOUT7 0V/12V
4 27 Tilt Alarm Indicator DIGITAL OUTPUT P35 DOUT6 0V/12V
5 65 Axle Lock DIGITAL OUTPUT P34 DOUT5 0V/12V
6 63 SGE Alarm DIGITAL OUTPUT P3B DOUT12 0V/12V
7 85 Generator Solenoid DIGITAL OUTPUT P3A DOUT11 0V/12V
8 68 Engine Run Enable DIGITAL OUTPUT P39 DOUT10 0V/12V
9 57A Engine Start Relay DIGITAL OUTPUT P38 DOUT9 0V/12V
10 N/U DIGITAL OUTPUT P3F DOUT16 0V/12V
11 N/U DIGITAL OUTPUT P3E DOUT15 0V/12V
12 40 Platform Level Down DIGITAL OUTPUT P5C DOUT14 0V/12V
13 24A Steer Left DIGITAL OUTPUT P31 DOUT2 0V/12V
14 D Drive Controller ANALOG INPUT AN16 AIN01 0.5 - 8.5V
15 Y Main Boom Elevation Controller ANALOG INPUT AN17 AIN02 0.5 - 8.5V
16 X Turret controller ANALOG INPUT AN18 AIN03 0.5 - 8.5V
17 N/U ANALOG INPUT AN19 AIN04
18 N/U ANALOG INPUT AN20 AIN05
19 R Riser Controller ANALOG INPUT AN21 AIN06 0.5 - 8.5V
20 128 Angle Sensor / Torque Mode ANALOG INPUT AN22 AIN07 1.0 - 5.0V
21 N/U ANALOG INPUT AN23 AIN08
22 N/U ANALOG INPUT AN25 AIN09
23 41 Platform Level Up DIGITAL OUTPUT P3C DOUT13 0V/12V
24 20 Load Sense Valve DIGITAL OUTPUT P32 DOUT3 0V/12V
25 08 Footswitch Indicator DIGITAL OUTPUT P33 DOUT4 0V/12V
26 40A Platform Level Down DIGITAL INPUT PC2 DIN19 0V/12V
27 N/U DIGITAL INPUT PC5 DIN20 0V/12V
28 37A Platform Rotate Right DIGITAL INPUT PC8 DIN21 0V/12V
29 36A Platform Rotate Left DIGITAL INPUT PCA DIN22 0V/12V
30 165A Diff Lock DIGITAL INPUT PCC DIN23 0V/12V
31 85A Generator DIGITAL INPUT PCE DIN24 0V/12V
32 61 Sensing Bar ( SGE) DIGITAL INPUT PD0 DIN25 0V/12V
33 62 Reset SGE DIGITAL INPUT PF4 DIN26 0V/12V
34 26 Holding Brake Off DIGITAL OUTPUT P06 DOUT17 0V/12V
35 165 Diff Lock DIGITAL OUTPUT P07 DOUT18 0V/12V
1344AA
