Section 5 – Procedures Deutz Diesel Engines
5.6-6 Deutz TD2.9L Fault Codes
Code SPN FMI Blink Code Error Identification
1264 523922 7 8-5-5 Burner Shut Off Valve; blocked open.
1285 524038 9 8-2-4
Timeout error of CAN-Receive-Frame ComMS_Sys1TO (error memory Slave);
Master-Slave internal CAN message.
1286 524039 9 8-2-5
Timeout error of CAN-Receive-Frame ComMS_Sys2TO (error memory Slave);
Master-Slave internal CAN message.
1287 524040 9 8-2-6
Timeout error of CAN-Receive-Frame ComMS_Sys3TO (error memory Slave);
Master-Slave internal CAN message.
1288 524041 9 8-2-7
Timeout error of CAN-Receive-Frame ComMS_Sys4TO (error memory Slave);
Master-Slave internal CAN message.
1289 524042 9 8-2-8
Timeout error of CAN-Receive-Frame ComMS_Sys5TO (error memory Slave);
Master-Slave internal CAN message.
1290 524043 9 8-2-9
Timeout error of CAN-Receive-Frame ComMS_Sys6TO (error memory Slave);
Master-Slave internal CAN message.
1291 524045 9 8-3-1
Master Slave, Error of message counter CAN receive message
ComMSMoFOvR; ComMSMoFOvR1CNT.
1292 524046 9 8-3-2 Master-Slave CAN; Error Checksum of CAN-Receive Message.
1293 524047 9 8-3-3
Master-Slave CAN; Error of message length of CAN receive message
ComMSMoFOvR;_ComMSMoFOvR1DLC.
1294 524048 9 8-3-4 Timeout error CAN message ComMSMoFOvR1TO error memory Slave.
1299 523788 0 6-5-5 Wastegate plauisibility error off CAN transmit message.
1300 523788 0 6-5-5 Timeout Error of CAN-Receive-Frame ComTrbChActr; Wastegate.
1302 524024 11 8-6-6
Deviation of the exhaust gas temperature setpoint to actual value
downstream (DOC) too high.
1324 523995 13 7-9-5
Check of missing injector adjustment value programming (IMA) injector 7 (in
firing order).
1325 523996 13 7-9-6
check of missing injector adjustment value programming (IMA) injector 8 (in
firing order).
1326 523997 4 7-9-7 Injector cylinder bank 1 slave; short circuit.
1327 523998 4 7-9-8 Injector cylinder bank 2 slave; short circuit.
1328 523999 12 7-9-9 Injector powerstage output Slave defect.
1329 524000 5 1-7-7 Injector 7 (in firing order); interruption of electric connection.
1330 524001 5 1-7-8 Injector 8 (in firing order); interruption of electric connection.
1333 524000 3 1-7-7 Injector 7 (in firing order); short circuit.
1334 524001 3 1-7-8 Injector 8 (in firing order); short circuit.
1337 2797 4 5-6-5
Timeout of Short-Circuit Ground Diagnosis Cyl. Bank 0;_
IVDiaShCirGndToutBnk_0.
1338 2798 4 5-6-6
Timeout of Short-Circuit Ground Diagnosis Cyl. Bank 1;_
IVDiaShCirGndToutBnk_1.
1339 2797 4 5-6-5 Injector diagnostic; Short circuit to ground cylinder bank 0.
1340 2798 4 5-6-6 Injector diagnostic; Short circuit to ground cylinder bank 1.
1513AA-16
