Deutz Diesel Engines Section 5 – Procedures
5.6-6 Deutz TD2.9L Fault Codes
Code SPN FMI Blink Code Error Identification
1341 524035 12 5-5-5 Injector diagnostics; time out error in the SPI communication.
1342 524036 12 5-5-5 Injector diagnostics Slave; time out error in the SPI communication.
1345 524069 9 8-9-6
Timeout Error of CAN-Receive-Frame MSMon_FidFCCTO; Master-Slave CAN
communication faulty.
1357 524052 11 8-3-6 Error memory Slave reports FID MSMonFC2 (collective error).
1368 524052 11 8-3-6 Error memory Slave reports FID MSMonFC3 (collective error).
1378 523919 2 6-9-4 Sensor air pump airpressure; plausibility error.
1379 523920 2 7-1-6 Sensor exhaust gas back pressure burner; plausibility error.
1380 3253 2 6-9-2 Sensor differential pressure (DPF); plausibility error.
1381 164 2 8-3-9 Rail pressure safety function is not executed correctly ().
1389 523922 5 7-1-5 Burner Shut Off Valve; open load.
1390 523922 12 7-1-5 Burner Shut Off Valve; powerstage over temperature.
1392 523922 4 7-1-5 Burner Shut Off Valve; short circuit to ground.
1395 523921 2 7-1-4
Burner temperature sensor; Plausibility Check for burner temperature sensor
Sensor burner temperature; plausibility error.
1398 1136 0 6-8-1 Physical range check high for ECU temperature.
1402 4769 2 6-8-4
Sensor exhaust gas temperature OxiCat downstream (normal operation);
plausibility error.
1403 4769 2 6-8-4
Sensor exhaust gas temperature OxiCat downstream (regeneration);
plausibility error.
1411 1188 11 8-1-4 Wastegate actuator; internal error.
1412 1188 11 8-1-4 Wastegate actuator; EOL calibration not performed correctly.
1413 1188 13 8-1-4 Wastegate actuator calibration deviation too large, recalibration required.
1414 1188 2 8-1-4 Wastegate; status message from ECU missing.
1415 1188 7 8-1-4 Wastegate actuator; blocked.
1417 1188 11 8-1-4 Wastegate actuator; over temperature (> 135°C).
1418 1188 11 8-1-4 Wastegate actuator; operating voltage error.
1423 51 0 5-9-4
Warning threshold for an internal actuator error exceeded, < 4L EGR.
actuator und >4L Air Intake Flap.
1424 51 1 5-9-4
Shut off threshold for an internal actuator error exceeded, < 4L EGR.actuator
und >4L Air Intake Flap.
1425 172 0 2-2-6 air temperature within air filter box above maximum physical value.
1431 524028 2 8-1-5 CAN message PROEGRActr; plausibility error.
1432 524029 2 8-1-5
Timeout Error of CAN-Receive-Frame ComEGRActr - exhaust gas
recirculation positioner.
1436 524034 5 8-1-6 Disc separator; open load.
1437 524034 12 8-1-6 Disc separator; powerstage over temperature.
1438 524034 3 8-1-6 Disc separator; short circuit to battery.
