Skyjack SJ85 AJ Service Manual

58
SJ85 AJ229044ADA
Section 3 – System Component Identification and Schematics Electrical Parts List
Index
No.
Skyjack
Part No.
Description
2H-21A 159821 COIL, Dump
2H-36A 159821 COIL, Flow enable platform/jib
2H-85 168057 COIL, Flow enable - generator
3H-165 159827 COIL, Diff. lock
3H-26 159827 COIL, Brake release
3H-45 159827 COIL, 2-spd
3H-65 159827 COIL, Axle lock out
4H-13 212554 COIL, Boom down
4H-14 212554 COIL, Boom up
4H-15 N/A COIL, Drive pump control
4H-16 N/A COIL, Drive pump control
4H-30 212554 COIL, Riser down
4H-31 212554 COIL, Riser up
4H-34 208881 COIL, Jib down
4H-35 208881 COIL, Jib up
4H-36 208881 COIL, Platform rotate left
4H-37 208881 COIL, Platform rotate right
4H-38 212554 COIL, Boom in
4H-39 212554 COIL, Boom out
4H-40 159821 COIL, Platform level down
4H-41 159821 COIL, Platform level up
5H-23A 208881 COIL, Steer right
5H-24A 208881 COIL, Steer left
5H-32 212554 COIL, Rotate left
5H-33 212554 COIL, Rotate right
A1 138225 CONTROLLER, Boom/turret
A2 148707 CONTROLLER, Riser
A3 138224 CONTROLLER, Drive/steer
AT1 149426 TRANSDUCER, Angle (tilt switch)
BP1 103057 ALARM, Tilt
BP2 103056 BEEPER, All motion alarm
BP3 144387 BEEPER, Overload alarm
BP4 166110 ALARM/FLASHER - SGE
BP5 131938 ALARM, Overload
CB1 117325 BREAKER, Circuit - 15 amp
CB2 117325 BREAKER, Circuit - 15 amp
CB3 117326 BREAKER, Circuit - 20 amp
CB4 117326 BREAKER, Circuit - 20 amp
CB5 117326 BREAKER, Circuit - 15 amp (generator)
CB40 171899 BREAKER, Circuit - 20 amp (positive air shut-off option)
H1 146652 HORN
LB1 171888 LIGHT, Work
LB2 171888 LIGHT, Work
LB2 144078 LIGHT, Flashing
LS1 199546 SWITCH, Limit - direction sensing
LS2 207059 SWITCH, Limit - boom down
LS3 198390 SWITCH, Limit - fly in
