Electrical Parts List Section 3 – System Component Identification and Schematics
Index
No.
Skyjack
Part No.
Description
LS4 198391 SWITCH, Limit - dual load zone
LS5 198390 SWITCH, Limit - dual load zone
LS6 207017 SWITCH, Limit - riser down
LS7 207059 SWITCH, Limit
OCM 208873 MODULE, SCM
PL3 133133 LIGHT, Pilot - MIL
PL4 133133 LIGHT, Pilot - low fuel
PL5 164832 LIGHT, Pilot - Oil pressure
PL6 164831 LIGHT, Pilot - Preheat
PL7 164832 LIGHT, Pilot - Coolant temperature
PL8 133133 LIGHT, Pilot - WTF
PL9 171501 LIGHT, Pilot - low capacity
PL10 171501 LIGHT, Pilot - high capacity
PL11 171502 LIGHT, Pilot - load zone border
PL12 171502 LIGHT, Pilot - low capacity
PL13 171501 LIGHT, Pilot - high capacity
PL14 171501 LIGHT, Pilot - load zone border
PL15 138229 LIGHT, Panel
PL16 171502 LIGHT, Pilot - diff lock
PL17 164832 LIGHT, Pilot - Overload
PL40 164832 LIGHT, Pilot - positive air shut-off option
R1 144523 RESISTOR, 7 ohm 25 W
R2 110999 RESISTOR, 5 ohm 25 W
R3 110999 RESISTOR, 3 ohm 25 W
R4 139088 RESISTOR, 6 ohm 25 W
R5 171987 RESISTOR, 1 ohm 1/4 W
S1 119725 SWITCH, Battery disconnect
S2 164949 SWITCH, Key - ANSI/CSA & AS
S2 165828 SWITCH, Key - CE
S3 144652 SWITCH, Emergency stop
S4 144647 SWITCH, Emergency stop
S5 138278 SWITCH, Toggle - ignition/e-pump switch
S6 144016 SWITCH, Toggle - e-pump
S9 124446 SWITCH, Toggle - Ignition
S10 115747 SWITCH, Toggle - throttle
S11 700187 SWITCH, Footswitch
S12 138278 SWITCH, Toggle - boom lift
S13 102853 SWITCH, Toggle - Tturret rorate
S14 102853 SWITCH, Toggle - Telescope
S15 102853 SWITCH, Toggle - platform levelling
S16 102853 SWITCH, Toggle - platform rotate
S17 102853 SWITCH, Toggle - jib up/down
S18 102853 SWITCH, Toggle - Telescope extend/retract
S19 102853 SWITCH, Toggle - Platform levelling
S20 102853 SWITCH, Toggle - platform rotate
S21 102853 SWITCH, Toggle - Jib up/down
S22 115747 SWITCH, Toggle - generator
