smart CX01 41
Value Meaning
Auto Default setting: the receiver selects optimum value
4:3PS For playback with a 4:3 screen, PS = Pan & Scan:
• 4:3 program: picture is optimally displayed.
• 16:9 program: picture height is adjusted to screen; picture infor-
mation on the right and left are missing.
4:3LB For playback with a 4:3 screen, LB = Letterbox
• 4:3 program: picture is optimally displayed.
• 16:9 program: picture width is adjusted to screen; lacking height is
filled up by black bars.
16:9 For playback with a 16:9 TV set
5.7.10 Video Resolution
In the menu System Setup, select the sub-menu TV System and confirm by
pressing OK.
1. Select Video Resolution.
2. Press OK to display a list with the selectable values.
3. Select the value appropriate to your TV set by using the keys PR+ and
PR-.
Example: If your TV set is capable of displaying a resolution of 720p
9F
10
then you should also set 720p at the receiver (720p is the factory setting).
If receiver and your TV set are connected via a SCART cable,
then max. resolution is 576i (PAL format).
In addition to the setting in
can be changed directly via the remote control:
Press (several times, if necessary) the green function key to
switch the resolution of the video signal at the HDMI out-
put. The set value is shown in the display.
10
p = progressive scan: progressive scan images are transmitted, e.g. 720p means that 50 progres-
sive scan images with a resolution of 1280 pixel/line and 720 lines/image are transmitted per sec-
ond.
i = interlaced video: odd and even lines are transmitted alternatingly.
