smart CX01 53
7. Confirm change of position by pressing Yes or discard such change by
pressing No.
8. Repeat the steps 1 to 6 for any further satellites/transponders, if applica-
ble.
Select Recalculation and press OK to discard any previous settings and
to again determine antenna position.
Press EXIT to return to the submenu Antenna Setup.
Select Limit setup and press OK
to open the window Limit set-
up.
1. Select Limit setup to switch between Disable Limit, West Limit and East
Limit.
2. Mark the button Limit setup and move the limit - as defined in the pre-
vious step - to the east or west by using the keys and .
3. Mark the button Go to Reference and then press OK to move the motor
antenna to its starting position.
4. Press EXIT to return to the submenu Antenna Setup.
7.1.3.2.2 USALS
A satellite position is defined as reference, and the data provided for latitude
and longitude are then used together with such basic values to calculate the
rotary movement for all remaining satellites.
Select Local Longitude to enter the longitude of the position of your an-
tenna by using the numeric keys of your remote control.
Select Local Latitude to enter the latitude of the position of your antenna
by using the numeric keys of your remote control.
Select Motor Setting and press
OK to open the submenu Motor
Setting.
1. Select Satellite to select the satellite that should be used as reference for
USALS control of the antenna.
