68 smart CX01
2. Select the menu item LNB Freq
to set Unicable(9750-10600).
3. Press the green function key to
open the window Antenna Setup
Unicable Setting.
4. Select the menu item IF Channel
and set the IF channels (start
with channel 1; respectively allo-
cate one of the IF channels - in
ascending order - to the con-
nected receivers).
5. Select the menu item Center Freq to set the frequency corresponding to the
IF channel (see allocation table).
6. Select the menu item Sat Position to set the respective satellite position.
7. Mark the button Save and press OK to save your entries and to return to the
first window Antenna Setup
or
mark the button Cancel and press OK to discard any previous entries in this
window and to return to the first window Antenna Setup without saving.
8. Press the red function key to
open the window Antenna Setup
Center Freq.
9. Leave the menu by pressing
EXIT (settings will be saved).
RAPS installation will be contin-
ued automatically.
