Calibration procedure
23
Start this procedure as follows:
A window opens under Options Service  Calibration object registration (Fig. 22).
Figure 22: Calibration model registration
Individual values are indicated on the rear of the calibration model. Please enter these in fields #1
and #2.
Confirm the procedure with "OK".
You can start the 3D calibration only by selecting the start command under the item Options
Service 3D calibration  Complete.
The system now performs a 3D calibration; this can take several minutes.
The following message will appear at the end of the calibration (Fig. 23).
Figure 23: Completing the calibration
The 3D calibration was successful. Confirm with "OK".
Repeat the calibration about every four weeks and each time the scanner is
transported in order to ensure the accuracy of the scan results.
