Scanning procedure
46
Figure 54: Complete jaw 3D scan
After the 3D scan, cut the data set if necessary. Now start the STL calculation with the Matching
button.
The matching process for a complete jaw can take up to several minutes, irrespective
of the number and size of the scans to be matched or the selected thinning level and
computer capacity.
The jaw scan is visualized in the 3D viewer as shown below:
Figure 55: 3D-STL data set
