Basic information about the device
26
The most important components and operating controls of the scanner are explained below.
Figure 24: Device front
Figure 25: Device rear
Lid/Case opening
Device designation
System drawer
Systemauszug
USB port for the motor and
scanner control
USB port for the camera
Fuse
Power cord connection
