Scanning procedure
39
If "Rescan Mode" is enabled, this green cross will be shown in the centre of the 3D viewer (see
above). Now the edge of the data hole must be positioned below the cross using the familiar
mouse options (left mouse button rotate, right mouse button move and scroll wheel zoom).
If the centre of a hole is positioned directly below the cross, the scanner will move to
an incorrect rescan position and possibly a recording at another point.
Figure 41: "Rescan" mode
Figure 42: "Rescan"
Cross hairs
next to the area
to be scanned
Area to undergo a
rescan
