APPENDIX A
REMOTELY MANAGING YOUR SYSTEM THROUGH A NETWORK INTERFACE
49 smarttech.com/kb/170549
Submenu setting Description
Aspect Ratio Adjusts the image output to Fill Screen, Match Input or 16:9.
l
Fill Screen produces an image that fills the entire screen by
stretching and scaling.
l
Match Input matches the projector’s aspect ratio to the input’s
aspect ratio. As a result, black bands might appear along the
top and bottom edges of the screen horizontally (letterbox
format) or along the left and right edges of the screen vertically
(pillarbox format).
l
16:9 changes the output to 16:9 by letterboxing the image,
which is recommended for use with HDTV and DVDs
enhanced for wide-screen television.
NOTE
See
Video format
on page77 for descriptions of each mode.
Startup Screen Sets the type of startup screen to SMART or User. The SMART
screen is the default SMART logo on a blue background. The User
screen uses the saved picture from the Capture User Startup
Screen function.
Video Mute Turns the video mute setting on or off. Select On to hide the display
and Off to show it again.
High Speed Fan Adjusts the speed of the projector’s fan. Select High or Normal.
NOTE
Use the High setting when the projector’s temperature is high or
the altitude is above 6000' (1800 m).
Projector Mode Adjusts the projection mode to Front, Ceiling, Rear or Rear Ceiling.
IMPORTANT
SMART recommends that you never change this setting from the
Ceiling projection mode.
Source Adjusts the input source to VGA-1, VGA-2, Composite, S-Video or
HDMI.
VGA1 Assigns an alternative name to your VGA 1 input, which appears
when you select the VGA 1 input.
VGA2 Assigns an alternative name to your VGA 2 input, which appears
when you select the VGA 2 input.
Composite Assigns an alternative name to your Composite video input, which
appears when you select the Composite video input.
HDMI Assigns an alternative name to your HDMI input, which appears
when you select the HDMI input.
