SMC Networks EX600 Series User Manual

-71-
No.EX※※-OMX1011
•Analogue I/O unit parameters (2)
No.
Parameter
Definition
Item
Content
Default
setting
Parameter
setting range
8
User’s set
value lower
limit error
Generates error
when the input or
output value falls
below the lower
limit.
Enable
Generates an error.
1
Channel
Disable
Does not generate an
error.

Scale lower
limit setting
Sets the scale
lower limit.
Generates error
when the input or
output value falls
below the lower
limit.
Enable
Generates an error.
Val: -32767 to 32766
Disable
Does not generate an
error.
Val: -32767 to 32766

Val: 0
9
Output setting
for
communication
fault
2
Sets output when
communication
error is occurred.
Enable
Output will be user fault
value.
1
Channel
Disable
Output will be held last
state.

10
Output setting
for
communication
idling
2 3
Sets output during
communication
idling.
Enable
Output will be user idle
value.
1
Channel
Disable
Output will be held last
state.

1: Set value shall be set per analogue output range within settable range in the table below.
When the analogue output range is changed, check the set value and change it to an appropriate value.
2: This function is valid only when "Hold/Clear priority" of the system parameter is set to "Via software".
3: Some PLC does not support an idle mode.
