-72-
No.EX※※-OMX1011
Settable range for user set upper or lower limit and output value at communication error and idling
Range
Settable range for user set upper or lower limit
Settable range for output
value at communication error
and idling
Lower limit
Upper limit
0..10 V
0.00 to +10.45 V
+0.05 to +10.50 V
0.00 to +10.50 V
0..5 V
0.00 to +5.22 V
+0.03 to +5.25 V
0.00 to +5.25 V
1..5 V
+0.75 to +5.22 V
+0.78 to +5.25 V
+0.75 to +5.25 V
0..20 mA
0.00 to +20.90 mA
+0.10 to +21.00 mA
0.00 to +21.00 mA
4..20 mA
+3.00 to +20.90 mA
+3.10 to +21.00 mA
+3.00 to +21.00 mA
Correspondence table for user set upper or lower limit and output value at communication error and
idling (E.O./W.S.)
(Data format: other than scale conversion format)
Range
Value
(Offset Binary Signed Magnitude 2’s Complement)
Expected value
0..10 V
0 to 1050
0.00 to +10.50 V
0..5 V
0 to 525
0.00 to +5.25 V
1..5 V
75 to 525
+0.75 to +5.25 V
0..20 mA
0 to 2100
0.00 to +21.00 mA
4..20 mA
300 to 2100
+3.00 to +21.00 mA
: When the data format is a type other than scale conversion, input the required voltage or current x 100 in decimal system.
: If the data format is scaled data format, set the data as follows, regardless of the range setting.
Correspondence table for user set upper or lower limit and output value at communication error and
idling (E.O./W.S.)
(Data format: scale conversion format)
E.O. set value
W.S. set value
Expected value
0 to 32767
0 to 32767
+0 to +32767
32768 to 65535
-0 to -32767
-0 to -32767
