-74-
No.EX※※-OMX1011
•IO-Link master unit parameters
No.
Parameter
Definition
Item
Content
Default
setting
Parameter
setting range
1
Process Data
Mapping
Define the process
data size of each
port of the IO-Link
master, which is
occupied by the
EtherNet/IP
communication.
2/2/2/2 byte
I/O size of port 1 to 4:
2 byte/2 byte for each

Unit
4/4/4/4 byte
I/O size of port 1 to 4:
4 byte/4 byte for each
8/8/8/8 byte
I/O size of port 1 to 4:
8 byte/8 byte for each
16/16/2/2 byte
I/O size of port 1 and 2:
16 byte/16 byte for each
I/O size of port 3 and 4:
2 byte/2 byte for each
32/2/2/2 byte
I/O size of port 1:
32 byte/32 byte each
I/O size of port 2 to 4:
2 byte/2 byte for each
2
InOut Byte
Swap
1
Swap the byte
order of the
process data,
which is sent and
received between
EtherNet/IP
communication
and IO-Link
master.
direct
Data order is not
swapped.

Unit
swap 16 bit
Swap in the word unit.
swap 32 bit
Swap in the double word
unit.
swap All
Swap all bytes.
3
Short Circuit
Monitor
Either of the
following detects
the short-circuit,
diagnostics is
generated.
•L+ power supply
•C/Q signal
•P24 power supply
Enable
Diagnostics is generated.

Unit
Disable
Diagnostics is not
generated.
4
Output setting
during
Communication
Fault
(IO-Link)
2
Set the IO-Link
communication
process data
output when the
EtherNet/IP
communication
error is occurred.
Clear/
PD Out valid
All outputs are turned
OFF while maintaining
the process data output
valid.
Unit
Hold
Maintain the process data
output that the IO-Link
master finally receives
while maintaining the
process data output valid.
Clear/
PD Out invalid
All outputs are turned
OFF while maintaining
the process data output
invalid.

