-75-
No.EX※※-OMX1011
•IO-Link master unit parameters (continued)
No.
Parameter
Definition
Item
Content
Default
setting
Parameter
setting range
5
Output setting
during
Communication
Fault
(DO_C/Q)
Set the digital
output signal when
an EtherNet/IP
communication
error is occurred.
Clear
Turn OFF the digital
output.

Unit
Hold
Maintain the digital output
that the IO-Link master
finally receives.
Force ON
Turn ON the digital
output.
6
Output setting
during
Communication
Idle
(IO-Link)
Set the IO-Link
communication
process data
output when the
EtherNet/IP
communication is
idling.
Clear/
PD Out valid
All outputs are turned
OFF while maintaining
the process data output
valid.
Unit
Hold
Maintain the process data
output that the IO-Link
master finally receives
while maintaining the
process data output valid.
Clear/
PD Out invalid
All outputs are turned
OFF while maintaining
the process data output
invalid.

7
Output setting
during
Communication
Idle
(DO_C/Q)
Set the digital
output signal when
EtherNet/IP
communication is
idling.
Clear
Turn OFF the digital
output.

Unit
Hold
Maintain the digital output
that the IO-Link master
finally receives.
Force ON
Turn ON the digital
output.
8
PortMode
Set the operation
mode of each port.
Deactivated
Deactivate the port.

Channel
IOL_Manual
Start-up IO-LINK
communication based on
the IO-Link device
comparison function.
IOL_Autostart
Start up the IO-Link
communication instead of
comparing IO-Link
device.
DI_C/Q
Digital input only.
DO_C/Q
Digital output only.
