COSMOS DRIVER SERIES 3000 - USE AND MAINTENANCE MANUAL
4.2.2 Model code
The specific features of each driver COSMOS 3000 are defined by an alpha-numeric code printed on the device label,
near the MODEL code. Here is the coding table.
Ver. 1.07 Pag. 16
MODEL * * * * * . * * * * * . * * * * *
Reserved
Reserved
Reserved
Reserved
Auxiliary power
1 = 24Vdc
Main power
1 = 230÷480Vac 3PH
Maximum output current – Asyncronous motor power
1 = 15Apk – 2.2kW
2 = 25Apk – 5.5kW
3 = 50Apk – 7.5kW
Safe Torque Off (STO) system
0 = Absent
1 = Present
Dynamic brake
0 = Absent
1 = Present
Brake resistor
0 = Absent
1 = 2,5kJ
2 = 5,0kJ
3 = 4,0kJ
4 = 0,8kJ
Encoder
0 = Absent
1 = Incremental 5V diff. phases and HALL TTL + Hiperface
2 = Hiperface
3 = Incremental 5V diff. phases and HALL TTL
4 = Incremental HTL 24V
5 = Incremental 5V diff. phases ande HALL TTL + Out
6 = Incremental 5V diff. phases andHALL TTL/diff.
Forced ventilation
0 = Absent
1 = 1x31,5CFM
2 = 2x31,5CFM
3 = 2x10.8CFM
Field bus physical layer
0 = Absent
1 = EIA-RS485
2 = Ethernet
3 = POF – Sercos II
VISIO 3000 support
* = Absent per Type 3150
* = Present per Type 3250/3500
0 = Absent
1 = Present
I/O Configuration
* = Absent
0 = Absent
1 = Type 1
2 = Type 2
