8.6 LEDs FBS
FBS LEDs (fieldbus status) concern the field bus status; the number of LEDs and the colours depend on the integrated
field bus.
8.6.1 Field bus FLxIO
Status FBS
Field bus firmware updating ON FLASH S
Field bus hardware error ON ON
Field bus hardware error ON OFF
Field bus initialization OFF FLASH S
Field bus communication error OFF FLASH Q
Field bus Master not active or regular
communication
OFF ON
FLASH S = 1Hz, FLASH Q = 8Hz
8.6.2 Field bus Sercos III
The signal is given according to the specifications included in the document “Generic Device Profile” version 1.1.2.1.1
dated 31 March 2009, developed by SERCOS III Working Group - TWG Profile”.
Status FBS
On,CP4 no error, priority 0 (CPT stm) OFF OFF ON
Loopback, changed from fast-forward to
loopback, priority 2
OFF OFF FLASH
Communication error, depending S-0-
1003, priority 0 (CPT stm)
FLASH OFF FLASH
SIII C1D, class 1 diagnosis, priority 1 ON OFF OFF
On, CP0..CP3, priority 0 (CPT stm) OFF ON OFF
Identification, address allocation or
configuration error or other identification
purposes, priority 3
OFF FLASH OFF
Off, no Sercos communication, priority 0
(CPT stm)
OFF OFF OFF
