COSMOS DRIVER SERIES 3000 - USE AND MAINTENANCE MANUAL
5.3.7.2 Encoder repetition output
This output is used for repeating some signals read by the encoder 1 input (E1); these signals are to be connected to
acquisition devices, for control processes. Please note that the output signals on connector E2, as well as the input
signals on connector E1 are not insulated from the 24VDC power supply.
Connector E2
Signature Signal
1
2 Phase B+
3 Phase B-
4 Signal Z+
5 Signal Z-
6
7
8
9
10
11 GND
12 Phase A+
13 Phase A-
14 NTC
15 NTC
SHELL Shield
Ver. 1.07 Pag. 43
