COSMOS DRIVER SERIES 3000 - USE AND MAINTENANCE MANUAL
4.2.3 Accessories
Depending on the model, the COSMOS 3000 drivers are supplied with a series of connectors for power, I/O and STO
connections. The same connectors can be ordered separately, as well as other accessories not supplied with the driver.
Here is a list of the order codes.
Item Order code
VISIO 3000 KZ010262
Connector 24VDC / J5 * KF101054
Connector LINE / J1 * KF101042
Connector MOTOR / J4 * KF101045
Connector DC BUS / J3 * KF101044
Connector BRAKE R / J2 * KF101043
Connector STO (except model 3502-DB) * KF101051
Connector I/O (model 3502-DB) * KF101048
Fan blower (models 315X/325X) * KM021008
Brake resistor (model 325X, except order No KZ010595) * KG020098
Brake resistor (only for model 325X order No KZ010595) * KG020101
Cable USB 2.0 type A mini B length: 3m→ EC100213
Software Smitec Winmicro KW050111
* = included in the driver
Ver. 1.07 Pag. 17
