COSMOS DRIVER SERIES 3000 - USE AND MAINTENANCE MANUAL
5.2.2 Signal installation
We consider as signal wiring the encoder inputs (E1, E2), the I/O modules of STO system (STO), the general I/O
modules, the USB connection (USB), the connection for the VISIO 3000 (HMI), the connections for the field bus (F1, F2,
FRX, FTX). They are all situated on the front side.
In order to avoid damaging the driver, all connections, except USB and HMI, must be
connected/disconnected while the driver is off and the auxiliary voltage is absent.
