5.3 Connectors wiring
Please find here below the features of the allowed cables and connectors, as well as the legend of each connection of
the drivers COSMOS 3000.
The drivers COSMOS 3000 are electronic devices, sensitive to electrostatic charges.
In order to avoid damages, it is necessary to adopt all preventive measures.
5.3.1 Auxiliary power supply input (24VDC/J5 )
The auxiliary power supply is essential for the driver operation; in fact from the auxiliary power supply you can infer the
necessary power for the inner electronic control .
The supplied connector is equipped with a double contact for each pole, in order to allow the connection of several
drivers in parallel.
CAUTION
It is necessary to strictly adhere to the polarity for the connection of the auxiliary voltage, in order to
avoid irreversible damages to the driver.
It is very important to strictly adhere to the voltage limits indicated in the specifications, in order to
avoid bad operation and/or irreversible damages.
ATTENTION
Il est nécessaire de respecter scrupuleusement la polarité de connexion de la tension auxiliaire afin
de ne pas risquer des pannes irrémédiables du variateur.
Il est nécessaire de respecter les limites de tension indiquées dans les spécifications afin de ne pas
provoquer de dysfonctionnements et / ou de pannes irrémédiables du variateur.
Connector type: Phoenix Contact TVFKC 1,5/2-ST (1713839) * **
Order code: KF101054
Features Conductor cross section
Connection in accordance
with
EN-VDE Solid min. 0,2mm²
Rated voltage 250V Solid max. 1,5mm²
Rated current 10A Stranded min. 0,2mm²
Stranded max. 1,5mm²
Insulating material PA Stranded ferrule without plastic sleeve, min. 0,25mm²
Flammability rating
(Standard UL 94)
V0 Stranded ferrule without plastic sleeve max. 1,5mm²
Stripping length 8mm Stranded ferrule with plastic sleeve min. 0,25mm²
Screwdriver to be used in
order to open the
connections
0,6 x
3,5mm
Stranded ferrule with plastic sleeve max. 1,5mm²
*= Use 60/75 °C wires only (UL)
**= Use Copper Conductors only (UL)
Ver. 1.07 Pag. 33
