COSMOS DRIVER SERIES 3000 - USE AND MAINTENANCE MANUAL
5.5.2 Protection for UL applications according to IEC/UL 61800-5-1 and C22.2 No.274
The characteristics of the recommended fuses are summarized in the following tables, depending on the COSMOS servo
drive model which they are used.
COSMOS 315X-325X
Manufacturer Mersen/Ferraz
Model FR10GR69V25
Class gR (IEC 60269-4)
Dimension 10x38 mm
Rated current 25 A
Working voltage 700 V AC
COSMOS 350X
Manufacturer Mersen/Ferraz
Model FR14GR69V40
Class gR (IEC 60269-4)
Dimension 14x51 mm
Rated current 40 A
Working voltage 700 V AC
Suitable For Use On A Circuit Capable Of Delivering Not More Than 5000 Arms Symmetrical
Amperes, 480 Vac Maximum when protected by semiconductor fuses model FR10GR69V25 by
Mersen for the COSMOS 315X-325X drives and by semiconductor fuses model FR14GR69V40 by
Mersen for the COSMOS 350X drive.
Ver. 1.07 Pag. 50
