COSMOS DRIVER SERIES 3000 - USE AND MAINTENANCE MANUAL
7.2.4 Measure menu
7.2.4.1 Models for brushless motor
Menu Entry Lev. Description
1.1
>MEASURES
- This section displays all size units measured by the
driver; moreover, it stores the minimum or maximum
values measured for some size units.
1.1.2
VBUS RMS [V]
- Root mean square voltage
1.1.2
VBUS DC [V]
- Rectified voltage
1.1.3
VBUS DC MIN [V]
- Rectified minimum mains voltage
1.1.4
VBUS DC MAX [V]
- Rectified maximum mains voltage
1.1.5
IQ RMS [A]
- Root mean square direct current
1.1.6
IQ MAX [A]
- Maximum direct current
1.1.7
ID RMS [A]
- Root mean square reverse current
1.1.8
ID MAX [A]
- Maximum reverse current
1.1.9
IQ RMS MEAN [A]
1.1.10
IRMS MEAN MAX[A]
1.1.11
SPEED [rpm]
- Motor rotation speed
1.1.12
SPEED MAX [rpm]
1.1.13
SPEED REF [rpm]
- Preset motor rotation speed
1.1.14
TORQUE [Nm]
- Torque generated by the motor
1.1.15
TORQUE MAX [Nm]
- Maximum torque generated by the motor
1.1.16
DRIVE TEMP
[°C]
- Driver dissipator temperature
1.1.17
DRIVE TEMP MAX
[°C]
- Maximum driver dissipator temperature
1.1.18
MOTOR TEMP
[°C]
- Motor temperature
1.1.19
MOTOR TEMP MAX
[°C]
- Maximum motor temperature
1.1.20
BRAKE TEMP
[°C]
1
- Dynamic brake resistor temperature
e1.1.21
BRAKE TEMP MAX
[°C]
1
- Dynamic brake resistor maximum temperature
1.1.22
BOARD TEMP
[°C]
- Logic board temperature
1.1.23
VDC MAIN [V]
- Auxiliary voltage
1.1.24
MEASURE RESET
1 Elimination of the maximum and minimum values
recorded
Options=No, Yes
Note 1: only for models with dynamic brake
Ver. 1.07 Pag. 58
