COSMOS DRIVER SERIES 3000 - USE AND MAINTENANCE MANUAL
7.2.4.2 Models for asynchronous motor
Menu Entry Lev. Description
1.1
>MEASURES
- This section displays all size units measured by the
driver; moreover, it stores the minimum or maximum
values measured for some size units.
1.1.2
VBUS RMS [V]
- Root mean square voltage
1.1.2
VBUS DC [V]
- Rectified voltage
1.1.3
VBUS DC MIN [V]
- Rectified minimum mains voltage
1.1.4
VBUS DC MAX [V]
- Rectified maximum mains voltage
1.1.5
IRMS [A]
- Root mean square current
1.1.6
IRMS MAX [A]
- Root mean square maximum current
1.1.7
SPEED [rpm]
- Motor rotation speed
1.1.8
SPEED MAX [rpm]
- Maximum value detected of motor rotation speed
1.1.9
DRIVE TEMP
[°C]
- Driver dissipator temperature
1.1.10
DRIVE TEMP MAX
[°C]
- Maximum driver dissipator temperature
1.1.11
MOTOR TEMP
[°C]
- Motor temperature
1.1.12
MOTOR TEMP MAX
[°C]
- Maximum motor temperature
1.1.13
BRAKE TEMP
[°C]
1
- Dynamic brake resistor temperature
1.1.14
BRAKE TEMP MAX
[°C]
1
- Dynamic brake resistor maximum temperature
1.1.15
BOARD TEMP
[°C]
- Logic board temperature
1.1.16
IRMS MEAN [A]
- Average root mean square current in the last 4
minutes
1.1.17
IRMS MEAN MAX [A]
- Maximum root mean square current in the last 4
minutes
1.1.18
VDC MAIN [V]
- Auxiliary voltage
1.1.19
MEASURE RESET
1 Elimination of the maximum and minimum values
recorded
Options=No, Yes
Note 1: only in models with dynamic brake
Ver. 1.07 Pag. 59
