COSMOS DRIVER SERIES 3000 - USE AND MAINTENANCE MANUAL
1.1.19
INP-DIG
- Digital input status.
1.1.20
OUT-DIG
- Digital output status.
1.1.21
INP-A1 [V]
- Analogue voltage 0-10V applied to input 1.
1.1.22
INP-A1-MIN [V]
- Minimum value of the analogue input 1.
1.1.23
INP-A1-MAX [V]
- Maximum value of the analogue input 1.
1.1.24
INP-A2 [V]
- Analogue voltage 0-10V applied to input 2.
1.1.25
INP-A2-MIN [V]
- Minimum value of the analogue input 2.
1.1.26
INP-A2-MAX [V]
- Maximum value of the analogue input 2.
1.1.27
OUT-A [V]
- Value of the analogue output 0-10V.
1.1.28
OUT-A MAX [V]
- Max value reached by the analogue output 0-10V.
1.1.29
BOARD TEMP
[°C]
- Logic board temperature.
1.1.30
VDC MAIN [V]
- Auxiliary voltage.
1.1.31
MEASURE RESET
1 Elimination of max and min values recorded
Options=No, Yes.
7.2.5 Status menu
7.2.5.1 Models for brushless motor
Menu Entry Lev. Description
1.2
>STATUS
- This section includes detailed information about the
driver status.
1.2.1
DRIVE STATE
- Driver status; see chapter 9.2 in order to decode any
errors
1.2.2
LAST ERRORS
- List of the last 3 errors; chapter 9.2 in order to
decode any errors
1.2.3
ERROR LIST CLEAR
1 Elimination of the error list.
Options=No, Yes
1.2.4
HARDWARE STATE
- It displays hardware diagnostic information
7.2.5.2 Sercos II Cosmos
Menu Entry Lev. Description
1.2
>STATUS
- This section includes detailed information about the
driver status.
1.2.1
DRIVE STATE
-
Driver status; see chapter 10.1 to decode the error.
1.2.2
LAST ERR
- List of the last 8 errors; see chapter 10.1 to decode
the errors.
1.2.3
SERCOS STATE
- Sercos interface status; see chapter 10.2 to decode
the errors.
1.2.4
LAST ERR
- List of the last 8 errors in the Sercos; see chapter
10.2 to decode the errors.
1.2.5
HARDWARE STATE
- It displays hardware diagnostic information.
1.2.6
RESET ERROR
1 It allows cancelling the list of the last errors.
Ver. 1.07 Pag. 61
