BT-T080R User’s Manual
- 6 -
position 4 (three positions). Ensure the midlines of mark and paper coincide;
9 Mark position 4 can only be located in non-thermal layer.
2) In using marks, it is recommended to use the following parameters:
9 L1 mark width: 8mm≤L1≤paper width
9 L2 mark height: 4mm≤L2≤8mm
3) The reflectivity of marks is less than 10%, and the reflectivity of other parts of the ticket within mark
width along paper feed direction is over 85%.
Figure 2.4.2 Mark position
Note:
Because of the paper shaking in the feeding and paper difference in parameter, the position fixed by mark
may have a tolerance of ±1mm.
2.4.3 Recommended paper
Paper type Manufacturer
TF50KS－E2C Nippon Paper Industries CO., LTD.
F240AC/F220-VP Mitsubishi Paper Mill CO., LTD.
KF060-FEAH NEW OJI Paper CO., LTD.
F70NA FUJI PHOTO FILM CO., LTD.
FV230A1 MITSUBISHI PAPER MILL CO., LTD.
Table 2.4.3 Recommended paper
Caution:
z Please use the recommended paper or its equivalents. Using other types of paper may affect print
quality and reduce the print head lifetime.
z Do not paste the paper to the shaft core.
z If the paper comes in contact with chemicals or oil, it may discolor or be less heat sensitive, which will
greatly affect the print quality.
z Do not rub the paper surface with a nail or hard metal. Otherwise it may discolor.
