3.3 Button and LED
Figure 3.3.1 Button and LED
Button function explanation:
Button Function Description
FEED
Printer feeds paper after
this button is pressed
down.
FEED button
LED status explanation:
LED Status Description
ERROR flash/off
The printer is abnormal. /
The printer is normal.
POWER on/off
The printer is powered
on. /The printer is
powered off.
3.4 Paper outlet module with LED (optional)
Figure 3.4.1 Print mechanism module (with paper outlet module)
1. Paper outlet (transparent) 2. LED
The function of the module:
1) Increase the length of paper outlet;
2) LED flashes and prompts.
Please refer to 3.2.2 for its overall size.
