SNBC BT-T080R - Cutter Technical Parameters

BT-T080R User’s Manual
- 3 -
Item Parameter (203dpi)
MTBF (main control
board)
360,000 hours
MTBF (printer) 5000 hours
Operation environment
0～50℃, 20～90%RH (40 )℃
Environment
Storage environment
-40～60℃, 20～93% RH (40 )℃
Overall size 100(L) X 157(W) X 123(H) (printer mechanism)
Physics Character
Weight About 1.7Kg (without paper roll)
Table 2.1 Technical specification parameters
Notes:
1) DPI: dots printed for each inch (One inch is about 25.4mm);
2) The real printing speed is related with data transmission speed, print darkness, print duty ratio,
control commands and input voltage, which may be lower than that in the above table.
2.2 Cutter technical parameters
Item Parameter Remark
Cut method Slide blade
Cut time 252ms Time for every cut
Cut interval 3s 20 times every minute (Max.)
Paper type
60～100μm
Thermal paper or common paper with
the same thickness
Work voltage 24VDC
Max. current 1.5A 24VDC
Cutter lifetime 1,000,000 times Including full cut and partial cut
Table 2.2 Cutter technical parameters
Full cut: The paper is cut off completely;
Partial cut: The paper is not cut off completely, with a little connection in the central area of the paper.
