StorEdge
Connection Unit
connection
LG Chem
RESU10H
battery
connection
Connection method
to the
StorEdge Connection
Unit
Recommended cable
type
(min-max AWG)
Control and monitoring
5-pin communication
terminal block:
6-pin connector
Press the protrusion at the
top of the terminal block to
open the connection hole,
insert the wire and release to
spring back and clamp the
wire.
5-wire shielded twisted pair
cable 24 AWG (16-24AWG),
600V insulated.
CAT5 600V insulated can
also be used.
En (Enable) ENABLE_H
V+ Not connected
B- (RS485)
1
RS485_L -
2
A+ (RS485)
1
RS485_H +
2
G (RS485) EN_G
1
Must be twisted pair
2
Must be twisted pair
SolarEdge StorEdge Installation Guide MAN-01-000262-1.2
36
Connecting to the Battery
