SolarEdge storedge User Manual

SE7600A-US
1
Unit
Lower Power Output Higher Power Output
Automatic switchover time < 2 sec
Typical Nighttime Power Consumption < 5 W
INPUT - DC (PV and BATTERY)
Transformer-less, Ungrounded Yes
Max Input Voltage 500 Vdc
Nom DC Input Voltage 400 Vdc
Reverse-Polarity Protection Yes
Ground-Fault Isolation Detection 600kΩ Sensitivity
Maximum Inverter Efficiency 98 %
CEC Weighted Efficiency 97.5 %
INPUT - DC (PV)
Maximum DC Power (STC) 10250 W
Max Input Current
2
23 Adc
2-pole Disconnection Yes
INPUT - DC (BATTERY) - FORHIGH POWER
Continuous Peak Power 3300 6600
Number and types of Batteries per
Inverter
Up to 2 for high capacity -
Tesla Powerwall 1
o
1 - LG Chem RESU10H
o
2 (for high power and high
capacity) - Tesla Powerwall1
(any combination other than
type B+B)
Max Input Current 8.5 17.5
DC Fuses on Plus and Minus 12A (field replaceable) 25A (field replaceable)
2-pole Disconnection Yes
ADDITIONAL FEATURES
Supported Communication Interfaces RS485 for battery, RS485, Ethernet, ZigBee (optional)
Battery Power Supply Yes, 12V / 53W
Revenue Grade Data, ANSI C12.1 Optional
3
Integrated AC, DC and Communication
Connection Unit
Yes
AC Disconnect Yes
Manual Inverter Bypass Switch Yes
1
These specifications apply to inverters with part numbers SE7600A-USS2XXXXX and connection unit model number
BCU-1PH-USS.
2
A higher current source may be used; the inverter will limit its input current to the values stated.
3
Revenue grade inverter P/N: SE7600A-USS20NNM2
115
StorEdge Single Phase Inverter with Connection Unit for High Power - Specifications
SolarEdge-StorEdge Specification MAN-01-00275-1.0

SolarEdge storedge Specifications

General

Type	Hybrid Inverter
Topology	Transformerless
Battery Compatibility	LG Chem, Tesla Powerwall
Communication Interfaces	RS485, Ethernet
Frequency	50 Hz / 60 Hz
Operating Temperature	-25°C to 60°C
Cooling	Convection cooling
