SolarEdge storedge User Manual

SE7600A-US Unit
Lower Power Output Higher Power Output
DC Voltage Rapid Shutdown (PV and
Battery)
Yes, according to NEC 2014 690.12
Auto-transformer thermal protection Yes
STANDARD COMPLIANCE (PENDING)
Safety UL1741, UL1699B, UL1998, CSA 22.2
Grid Connection Standards IEEE1547, Rule 21, Rule 14
Emissions FCC part15 class B
INSTALLATION SPECIFICATIONS
AC Output (Loads/Grid) conduit size /
AWG range
1 / 14-6 in/AWG
AC Output (Backup) conduit size /
AWG range
0.75-1 knockouts / 14-6 in/AWG
AC Input (Auto-transformer) conduit
size / AWG range
0.75-1 / 14-6 in/AWG
DC Input (PV) conduit size / AWG
range
0.75 / 14-8 in/AWG
DC Input (Battery) conduit size / AWG
range
0.75 / 16-10 in/AWG
Dimensions with Connection Unit
(HxWxD)
37 x 12.5 x 7.2 / 940 x 315 x 184 in / mm
Weight with Connection Unit 58.5 / 26.5 lb / kg
Cooling Natural convection and internal fan (user replaceable)
Noise < 50 dBA
Min - Max Operating Temperature -13 to +140 / -25 to +60 °F / °C
Protection Rating NEMA 3R
StorEdge Single Phase Inverter with Connection Unit for High Power - Specifications
3
SolarEdge-StorEdge Specification MAN-01-00275-1.0

SolarEdge storedge Specifications

General

Type	Hybrid Inverter
Topology	Transformerless
Battery Compatibility	LG Chem, Tesla Powerwall
Communication Interfaces	RS485, Ethernet
Frequency	50 Hz / 60 Hz
Operating Temperature	-25°C to 60°C
Cooling	Convection cooling
