SON PXW-FX9V - Page 19

16
9. HDMI OUT
No.
Signal
I/O
Specifications
1
TMDS DATA2+
OUT
TMDS data 2 (+) output
2
TMDS DATA2 SHIELD
—
GND for TMDS data 2
3
TMDS DATA2-
OUT
TMDS data 2 (-) output
4
TMDS DATA1+
OUT
TMDS data 1 (+) output
5
TMDS DATA1 SHIELD
—
GND for TMDS data 1
6
TMDS DATA1-
OUT
TMDS data 1 (-) output
7
TMDS DATA0+
OUT
TMDS data 0 (+) output
8
TMDS DATA0 SHIELD
—
GND for TMDS data 0
9
TMDS DATA0-
OUT
TMDS data 0 (-) output
10
TMDS CLOCK+
OUT
TMDS clock signal (+) output
11
TMDS CLOCK SHIELD
—
GND for TMDS clock
12
TMDS CLOCK
OUT
TMDS clock signal (-) output
13
CEC (N.C.)
— —
14
RESERVED (N.C.)
—
No connection
15
SCL
OUT
Serial data clock signal output
16
SDA
IN/OUT
Serial data signal input/output
17
DDC/CEC GND
—
GND
18
+5 V POWER
OUT
+5 V dc output
19
HPD
IN
Hot plug detect signal input
10. REMOTE
2.5 mm stereo mini mini jack
- External View -
Type A
19 1
18 2
